Shanghai Gubot is a famous brand in China .we are professional produce the wheel repair machine .Have cooperation with more than 1500 clients all over the world.
First :Please open the link to view the machine video:
https://youtu.be/Gl_aqqF7_xI
Second: technical parameters
| Items | Unit | Specifications | Remark |
| Max swing over bed | mm | 660 | |
| Max size of alloy wheel | inch | 28 | |
| Range of spindle speed | rpm | 50-2000 | |
| Cutting feed speed | mm/min | 0.1-1800 | |
| Xmoving speed of X axis and Z axis | mm/min | 12000 | |
| X-axis moving distance | mm | 660 | |
| Z axis movement speed | mm/min | 12000 | |
| Z axis moving distance | mm | 800 | |
| Tool holder form | - | Row of knives | |
| Tool bar size | mm | 25*25 | |
| Spindle length | mm | 360 | |
| X-axis, Z-axis motor type | - | servo motor | |
| Moving track | - | Taiwan imported rail | |
| main motor power | KW | 3 | |
| Feed motor | N/m | X:4 Z:4 | |
| Machine positioning accuracy | mm | 0.01 | |
| Machine tool positioning repeatability | mm | 0.01 | |
| Machine weight | KG | 1700 | |
| Machine size | mm | 2150*1280*1810 |
Third, the machine tool optional configuration:
1. German imported guide rails, Taiwan imported rails, imported screw rods, rails;
2. Imported servo motor and Panasonic sensor;
3. Electro-hydraulic tool holder;
4. Hydraulic power chuck;
Fourth, the machine tool standard configuration:
1. Gubert has independently developed the “Gubotlathe” control system;
2. Panasonic infrared displacement sensor;
3, X, Z axis linear guide;
4. Automatic lubrication system;
5, the cover completely protects the cover;
6, rail protection system;
7, precision machining parts;
8. Import handwheels;
9, LCD touch screen;
10, precision spindle unit
11, circuit protection system
12, remote assistance hardware and software, wireless mouse;
13, rack, row of knives, corresponding tool sets;
14, signal analog conversion module, precision motor
